Inkplate Features Comparison
For a quick overview of the features available across different Inkplate models (including some retired ones), see the table below. Click the name of the model you wish to inspect, or use the left and right arrows to browse through the list.
Inkplate 2
Inkplate 4TEMEPRA
| Feature | Value |
|---|---|
| Screen Size | 2.13" |
| Resolution | 202x104 |
| Great for | Small form factor projects or wearables |
| Color | Yes (Black, White, Red) |
| Partial update | No |
| Touchscreen | No |
| Full refresh time | 21s (with red color) |
| Fast refresh time | 12s (black and white) |
| Grayscale levels | - |
| Battery option | Yes (3000mAh), available here |
| Battery support | Yes, Li-ion 2-pin JST battery connector |
| Battery charger | Yes, charge via USB-C |
| Low-Power | Yes (25µA sleep) |
| Microcontroller | ESP32 |
| Wi-Fi | Yes |
| Arduino support | Yes |
| RTC | Yes (PCF85063A) |
| Qwiic (ex. easyC) connector | Yes |
| MicroSD | No |
| Additional sensors and actuators | No |
| All-In-One | Yes |
| Backlight | No |
| Made in EU | Yes |
| Open Source Hardware | Yes |
| Store page | Inkplate 2 on Soldered.com |
